Wavelength Insensitive Coupler

Category:Optical Passive Chip

Wavelength Insensitive Coupler (WINC) based on Planar Lightwave Circuit technology splits optical power into two ports with a certain ratio in a wide wavelength range from 1260nm to 1650nm. Solorein’s WINC family provides N×(2×2) array chip with different tap ratios from 5% to 50% with high performance and reliability (N=1, 4, 8 or customized). The products meet Telcordia GR-1221 and RoHS requirements.Solorein also provides customized designs to meet specialized requirements.

●Low Insertion Loss
●Low PDL
●Compact Size

●FTTx Deployments
●CATV Links
●Optical Measurement Equipments
